# ivreg: Two-stage least-squares regression with diagnostics

The ivreg function for instrumental variables regression had first been introduced in the AER package but is now developed and extended in its own package of the same name. This post provides a short overview and illustration.

## Package overview

The **ivreg** package (by John Fox,
Christian Kleiber, and
Achim Zeileis) provides a comprehensive implementation of instrumental variables
regression using two-stage least-squares (2SLS) estimation. The standard
regression functionality (parameter estimation, inference, robust covariances,
predictions, etc.) is derived from and supersedes the `ivreg()`

function in the
**AER** package. Additionally, various
regression diagnostics are supported, including hat values, deletion diagnostics such
as studentized residuals and Cook’s distances; graphical diagnostics such as
component-plus-residual plots and added-variable plots; and effect plots with partial
residuals.

An overview of the package along with vignettes and detailed documentation etc. is available on its web site at https://john-d-fox.github.io/ivreg/. This post is an abbreviated version of the “Getting started” vignette.

The **ivreg** package integrates seamlessly with other packages by providing suitable S3 methods,
specifically for generic functions in the
base-R **stats** package, and in the
**car**,
**effects**,
**lmtest**, and
**sandwich** packages,
among others. Moreover, it cooperates well with other object-oriented packages for
regression modeling such as **broom**
and **modelsummary**.

## Illustration: Returns to schooling

For demonstrating the **ivreg** package in practice, we investigate
the effect of schooling on earnings in a classical model for wage determination.
The data are from the United States, and are provided in the package as
`SchoolingReturns`

. This data set was originally studied by David Card, and was subsequently
employed, as here, to illustrate 2SLS estimation in introductory econometrics textbooks.
The relevant variables for this illustration are:

```
data("SchoolingReturns", package = "ivreg")
summary(SchoolingReturns[, 1:8])
## wage education experience ethnicity smsa
## Min. : 100.0 Min. : 1.00 Min. : 0.000 other:2307 no : 864
## 1st Qu.: 394.2 1st Qu.:12.00 1st Qu.: 6.000 afam : 703 yes:2146
## Median : 537.5 Median :13.00 Median : 8.000
## Mean : 577.3 Mean :13.26 Mean : 8.856
## 3rd Qu.: 708.8 3rd Qu.:16.00 3rd Qu.:11.000
## Max. :2404.0 Max. :18.00 Max. :23.000
## south age nearcollege
## no :1795 Min. :24.00 no : 957
## yes:1215 1st Qu.:25.00 yes:2053
## Median :28.00
## Mean :28.12
## 3rd Qu.:31.00
## Max. :34.00
```

A standard wage equation uses a semi-logarithmic linear regression for `wage`

, estimated by
ordinary least squares (OLS), with years of `education`

as the primary explanatory variable,
adjusting for a quadratic term in labor-market `experience`

, as well as for factors
coding `ethnicity`

, residence in a city (`smsa`

), and residence in the U.S. `south`

:

```
m_ols <- lm(log(wage) ~ education + poly(experience, 2) + ethnicity + smsa + south,
data = SchoolingReturns)
summary(m_ols)
## Call:
## lm(formula = log(wage) ~ education + poly(experience, 2) + ethnicity +
## smsa + south, data = SchoolingReturns)
##
## Residuals:
## Min 1Q Median 3Q Max
## -1.59297 -0.22315 0.01893 0.24223 1.33190
##
## Coefficients:
## Estimate Std. Error t value Pr(>|t|)
## (Intercept) 5.259820 0.048871 107.626 < 2e-16 ***
## education 0.074009 0.003505 21.113 < 2e-16 ***
## poly(experience, 2)1 8.931699 0.494804 18.051 < 2e-16 ***
## poly(experience, 2)2 -2.642043 0.374739 -7.050 2.21e-12 ***
## ethnicityafam -0.189632 0.017627 -10.758 < 2e-16 ***
## smsayes 0.161423 0.015573 10.365 < 2e-16 ***
## southyes -0.124862 0.015118 -8.259 < 2e-16 ***
## ---
## Signif. codes: 0 '***' 0.001 '**' 0.01 '*' 0.05 '.' 0.1 ' ' 1
##
## Residual standard error: 0.3742 on 3003 degrees of freedom
## Multiple R-squared: 0.2905, Adjusted R-squared: 0.2891
## F-statistic: 204.9 on 6 and 3003 DF, p-value: < 2.2e-16
```

Thus, OLS estimation yields an estimate of 7.4%
per year for returns to schooling. This estimate is problematic, however, because it can be argued
that `education`

is endogenous (and hence also `experience`

, which is taken to be `age`

minus
`education`

minus 6). We therefore use geographical proximity to a college when growing
up as an exogenous instrument for `education`

. Additionally, `age`

is the natural
exogenous instrument for `experience`

, while the remaining explanatory variables can be considered
exogenous and are thus used as instruments for themselves.
Although it’s a useful strategy to select an effective instrument or instruments for each endogenous
explanatory variable, in 2SLS regression all of the instrumental variables are used to estimate all
of the regression coefficients in the model.

To fit this model with `ivreg()`

we can simply extend the formula from `lm()`

above, adding a second
part after the `|`

separator to specify the instrumental variables:

```
library("ivreg")
m_iv <- ivreg(log(wage) ~ education + poly(experience, 2) + ethnicity + smsa + south |
nearcollege + poly(age, 2) + ethnicity + smsa + south,
data = SchoolingReturns)
```

Equivalently, the same model can also be specified slightly more concisely using three parts on the right-hand side indicating the exogenous variables, the endogenous variables, and the additional instrumental variables only (in addition to the exogenous variables).

```
m_iv <- ivreg(log(wage) ~ ethnicity + smsa + south | education + poly(experience, 2) |
nearcollege + poly(age, 2), data = SchoolingReturns)
```

Both models yield the following results:

```
summary(m_iv)
## Call:
## ivreg(formula = log(wage) ~ education + poly(experience, 2) +
## ethnicity + smsa + south | nearcollege + poly(age, 2) + ethnicity +
## smsa + south, data = SchoolingReturns)
##
## Residuals:
## Min 1Q Median 3Q Max
## -1.82400 -0.25248 0.02286 0.26349 1.31561
##
## Coefficients:
## Estimate Std. Error t value Pr(>|t|)
## (Intercept) 4.48522 0.67538 6.641 3.68e-11 ***
## education 0.13295 0.05138 2.588 0.009712 **
## poly(experience, 2)1 9.14172 0.56350 16.223 < 2e-16 ***
## poly(experience, 2)2 -0.93810 1.58024 -0.594 0.552797
## ethnicityafam -0.10314 0.07737 -1.333 0.182624
## smsayes 0.10798 0.04974 2.171 0.030010 *
## southyes -0.09818 0.02876 -3.413 0.000651 ***
##
## Diagnostic tests:
## df1 df2 statistic p-value
## Weak instruments (education) 3 3003 8.008 2.58e-05 ***
## Weak instruments (poly(experience, 2)1) 3 3003 1612.707 < 2e-16 ***
## Weak instruments (poly(experience, 2)2) 3 3003 174.166 < 2e-16 ***
## Wu-Hausman 2 3001 0.841 0.432
## Sargan 0 NA NA NA
## ---
## Signif. codes: 0 '***' 0.001 '**' 0.01 '*' 0.05 '.' 0.1 ' ' 1
##
## Residual standard error: 0.4032 on 3003 degrees of freedom
## Multiple R-Squared: 0.1764, Adjusted R-squared: 0.1747
## Wald test: 148.1 on 6 and 3003 DF, p-value: < 2.2e-16
```

Thus, using two-stage least squares to estimate the regression yields a much larger
coefficient for the returns to schooling, namely 13.3% per year.
Notice as well that the standard errors of the coefficients are larger for 2SLS estimation
than for OLS, and that, partly as a consequence, evidence for the effects of `ethnicity`

and the quadratic component of `experience`

is now weak. These differences are brought
out more clearly when showing coefficients and standard errors side by side, e.g., using the
`compareCoefs()`

function from the **car** package or the `msummary()`

function from the
**modelsummary** package:

```
library("modelsummary")
m_list <- list(OLS = m_ols, IV = m_iv)
msummary(m_list)
```

OLS | IV | |
---|---|---|

(Intercept) | 5.260 (0.049) |
4.485 (0.675) |

education | 0.074 (0.004) |
0.133 (0.051) |

poly(experience, 2)1 | 8.932 (0.495) |
9.142 (0.564) |

poly(experience, 2)2 | -2.642 (0.375) |
-0.938 (1.580) |

ethnicityafam | -0.190 (0.018) |
-0.103 (0.077) |

smsayes | 0.161 (0.016) |
0.108 (0.050) |

southyes | -0.125 (0.015) |
-0.098 (0.029) |

Num.Obs. | 3010 | 3010 |

R2 | 0.291 | 0.176 |

R2 Adj. | 0.289 | 0.175 |

AIC | 2633.4 | |

BIC | 2681.5 | |

Log.Lik. | -1308.702 | |

F | 204.932 |

The change in coefficients and associated standard errors can also be brought out graphically
using the `modelplot()`

function from **modelsummary** which shows the coefficient estimates
along with their 95% confidence intervals. Below we omit the intercept and experience terms
as these are on a different scale than the other coefficients.

```
modelplot(m_list, coef_omit = "Intercept|experience")
```
